Revel F226Be Floorstanding Loudspeaker
A three-way with 2 x 6.5″ woofers and 1″ beryllium tweeterÂ
Step into Revel’s world of reference-grade sound at affordable prices. The Revel F226Be, the most compact floorstander in the acclaimed PerformaBe series, is designed for audiophiles who want big-speaker performance in a smaller footprint. The F226Be combines cutting-edge driver technology with refined industrial design.
Beryllium Tweeter with Advanced Waveguide
At the heart of the F226Be is an engineering marvel: a 1″ (25 mm) beryllium dome tweeter powered by massive 85 mm dual ceramic magnets. This ultra-rigid, ultra-light tweeter is paired with Revel’s fifth-generation Acoustic Lens waveguide—crafted from ceramic-coated, cast aluminum—for unparalleled control over dispersion and directivity. The result is stunningly precise imaging, lifelike dynamics, and a wide, even soundstage that pulls you deep into the music.
Compact Cabinet, Commanding Performance
The F226Be delivers commanding performance with lower distortion, wider bandwidth, and increased power handling—outclassing aluminum and titanium tweeters in every regard. Whether you’re using them for music or integrating them into a reference home theater, these towers are built to disappear sonically.
Features
- 1-inch beryllium dome tweeter
- 5th-generation Acoustic Lens Waveguide
- Deep ceramic composite (DCC) cone midrange and woofers
- High-order crossovers with film capacitors and air core inductors
- Magnetically attached grilles
Specifications
Type: Three-way dual 6.5″ floorstanding loudspeaker
Enclosure Type: Bass-reflex via front-mounted port
Drivers
HF: 1″ (25 mm) beryllium dome, with acoustic lens waveguide
Mid: 5-1/4″ (130 mm) deep ceramic composite aluminum cone, with cast frame
LF: 2 x 6.5″ (165 mm) deep ceramic composite aluminum cones, with cast frames
Frequency Response (-6 dB): 44 Hz – 40 kHz
Low-Frequency Extension (-10 dB, -6 dB, -3 dB): 33 Hz, 36 Hz, 48 Hz
Nominal Impedance: 8 Ω
Sensitivity (2.83 V/1 m): 90 dB
Crossover Frequencies: 260 Hz, 2.1 kHz
Inputs: Dual gold-plated binding posts with shorting straps
Dimensions (WHD): 9.8″ x 41.3″ x 13.7″ (249 x 1050 x 347 mm)
Weight: 58 lb. (26.4 kg)
