Ortofon MC 90X: Redefine Your Vinyl Experience
Step into the pinnacle of analog playback with the Ortofon MC 90X, this limited‑edition moving coil cartridge marries Ortofon’s century‑old heritage with state‑of‑the‑art SLM stainless‑steel technology, delivering unparalleled groove‑tracing accuracy and a dynamically rich soundstage.
- Precision Engineering: Selective Laser Melted stainless‑steel body with Field Stabilizing Element (FSE) for ultra‑rigid resonance control.
- Immersive Clarity: Double‑polished Replicant 100 diamond stylus on a boron cantilever reveals every nuance of your records.
- Wide‑Range Performance: 20 Hz–20 kHz frequency response (±1 dB) with channel separation> 28 dB for a balanced, transparent presentation.
- Luxury Finishes: Matte cobalt blue housing with gold‑plated Aucurum coil wire—beauty and performance in one package.
Ready to elevate your listening sessions? Add the Ortofon MC 90X to your cart and experience vinyl as you’ve never heard it before.
| Technical Specifications | |
|---|---|
| Type | Moving Coil Cartridge |
| Stylus | Replicant 100 Diamond, Nude |
| Cantilever | Boron |
| Stylus Tip Radius | r/R 5/100 µm |
| Output Voltage | 0.25 mV (1 kHz, 5 cm/s) |
| Frequency Response | 20 Hz – 20 kHz ±1 dB |
| Channel Separation | > 28 dB (1 kHz) |
| Channel Balance | < 0.2 dB (1 kHz) |
| Tracking Force | 2.3 g (Recommended) |
| Internal Impedance | 4 Ω |
| Coil Wire | Aucurum (Gold‑plated 6NX OFC) |
| Body Material | SLM Stainless Steel |
| Damping System | Wide Range Damping, Ortofon Rubber Dampers |
| Field Stabilizing Element | Yes |
| Cartridge Weight | 9.5 g |
| Color | Matte Cobalt Blue |
