WELL-DAMPED BILLET ALUMINUM BODY
The well-damped billet aluminum body controls resonances for tight, accurate bass reproduction. MasterTracker has the lightest-weight magnets in the Tracker Series, delivering the kind of detailed, open performance normally attributed to high-end moving-coil cartridges.
MICRO-LINE DIAMOND STYLUS
By using a Micro-Line diamond stylus shaped like the cutting head of a record lathe, MasterTracker traces vinyl groove walls with microscopic precision.
SPECIFICATIONS
Type
Dual Magnet (MM) Stereo
Stylus
Micro-Line
Output Voltage
3mV
Frequency Response
20–25,000Hz
Weight
9.7g
Tracking Force
1.8–2.2g
Impedance
47kOhm
Capacitance
100pF
Compliance
Static compliance : 40 x 10e-6/dyne
Dynamic compliance : 10 x 10e-6/dyne
FEATURES
• V-Twin dual-magnet generator
• Micro-Line stylus with tapered cantilever
• Well-damped billet aluminum body
• Ohno continuous cast copper coils
• 3mV output
In The Box
MasterTracker Cartridge
with Stylus Guard
2. Stylus Cleaning Brush
3. Hex Driver
4. 2.5mm x 8mm Hex Screw (2)
5. 2.5mm x 10mm Hex Screw (2)
6. 2.5mm Metal Washer (2)
7. 2.5mm Nylon Washer (2)
