Marantz 2238B: Elevate Your Audio Experience with Vintage Fidelity
Step into the world of vintage audio excellence with the Marantz 2238B Stereophonic Receiver. Manufactured in the late 1970s, this receiver epitomizes the rich, warm sound that audiophiles crave. With a power output of 42 watts per channel into 8Ω, the Marantz 2238B ensures a robust and dynamic audio performance that brings your favorite music to life.
Whether you’re tuning into classic FM radio or connecting a modern streaming device, the Marantz 2238B offers unparalleled versatility and reliability. Its exceptional frequency response from 10Hz to 40kHz captures the full audible spectrum, delivering crisp highs and deep lows. The low total harmonic distortion of just 0.1% preserves the purity of sound, while a damping factor of 40 maintains tight control over speaker drivers.
Technical Specifications
| Specification | Details |
|---|---|
| Tuning Range | FM, MW |
| Power Output | 42 watts per channel into 8Ω (stereo) |
| Frequency Response | 10Hz to 40kHz |
| Total Harmonic Distortion | 0.1% |
| Damping Factor | 40 |
| Input Sensitivity | 1.8mV (MM), 180mV (line) |
| Signal to Noise Ratio | 50dB (MM), 50dB (line) |
| Output | 180mV (line), 1.5V (Pre out) |
| Semiconductors | 3 x IC, 46 x transistors, 34 x diodes, 1 x FET |
| Dimensions | 440 x 137 x 365mm |
| Weight | 12.5kg |
