The ATOLL CD100 CD player is a premium French-designed audio component that delivers high-resolution playback with remarkable clarity and detail. Featuring a Burr-Brown PCM1796 DAC, discrete Class A output stages, and robust linear power supplies, it ensures precise digital-to-analog conversion and dynamic performance. Compatible with CD, CD-R, CD-RW, MP3, and WMA formats, the CD100 also offers upgrade potential with an optional 24-bit/192 kHz digital input board.
,
- 4 mm brushed aluminium front panel
- 10 regulated power supplies, including a specific low-noise one for the converter
- Linear power supply for digital stages with a specific 30 VA transformer
- Separate 10 VA linear transformers for audio stages
- 1.6 VA transformer (low consumption)
- Original TEAC central CD mechanism (latest generation)
- Pure audio CD player compatible with:
- CD
- CD-R
- CD-RW
- MP3
- WMA-AAC
- Double-sided circuit boards with nickel/gold finish
- BURR-BROWN PCM1796 converter:
- 24-bit/192 kHz
- Dynamic range: 124 dB
- Signal-to-noise ratio: 124 dB
- Low-power OLED display
- CD-Text display
- Differential audio output stages with discrete components biased in Class A
- ATOLL global remote control
- Optional 24-bit/192 kHz digital card for all Evolution series CD players
- Outputs:
- 1 Line digital output (Right & Left)
- 1 Coaxial digital output (to a D/A converter)
- 1 Optical digital output (to a D/A converter)
- 12V Trigger output
- Optional Digital Board:
- USB input (Type B)
- Digital input (Coaxial)
- Digital input (Optical)
,
- Power Supply: 30 + 10 + 1.6 VA
- Total Capacitance: 21,450 µF
- D/A Converter: PCM1796
- Dynamic Range: 123 dB
- Signal-to-Noise Ratio: 123 dB
- Distortion at 1 kHz: 0.0005%
- Output Level: 2.10 Vrms
- Output Impedance: 5.6 Ω
- Bandwidth: 5 Hz – 20 kHz
- Rise Time: 2.0 µs
- Standby Power Consumption: <0.5 W
- Operating Power Consumption: 10 to 19 W
- Dimensions (W × D × H): 440 × 280 × 95 mm
- Weight: 6 kg
