Air Bearing Technology’s unique wrap around dove tail design allows the air slide to be mounted in any position. The fixed clearance design yields maximum stage loading.
Gas lubrication films are minimal, using an 8 micron film thickness for minimal air requirements with maximum stiffness and load capability.
Frictionless motion from bearing system, High precision dovetail design allows mounting in any orientation Three point mounting preserving accuracy of travel, Excellent skew resistance
The design eliminates the need for right and left hand slides on multi-axis systems.
, Nema 4 Mounting, Ultra Precise Straightness of Travel, Left or Right hand Mounting with same unit, Flag rails for home and over travel protection.
